China 2x6 Multi-port Modular Jack RJ45 with transformer, shielded with EMI fingers, built-in LED wholesale

2x6 Multi-port Modular Jack RJ45 with transformer, shielded with EMI fingers, built-in LED

Name: 2x6 Multiport Modular Jack RJ45 with transformer shielded with EMI fingers builtin LED
Brand: Heling
Price: 0.15 USD

Ask Latest Price

Video Channel

Place of Origin :China

Brand Name :Heling

Model Number :MJ007-BX24-RSL1T3

Certification :RHOS

Packaging Details :Tray

Delivery Time :2-5 weeks

Payment Terms :T/T in advance

Supply Ability :500k per month

MOQ :1000pcs

Price :0.15-0..99 USD

Contact Now

Add to Cart

View Product Description

Part No. MJ007-BX24-RSL1T3

Product description: 2x6 Multi-port Modular Jack RJ45 with transformer, shielded with EMI fingers, built-in LED

Material

Insulator:High Temp Nylon flammability rating UL94V-0. Available in black, yellow, blue, and red
Contacts: Phosphor Bronze with gold thickness options(6u”, 15u”, 30u”, 50u”) over 50u” minimum nickel on contact mating area

Shield:Copper alloy with nickel plating

LED:Tin plating on LED tail. Epoxy lens.

Electrical Characteristics

Voltage Rating:125 V AC(RMS)
Current Rating:1.5 AMP
Contact Resistance: 20mΩ Max.
Insulation resistance: 500MΩ Min.
Dielectric withstanding voltage: 1000 VAC RMS 60Hz, 1 Min.

Mechanical Characteristics

Durability:750 mating & unmating cycles

Mated Retention Force: 7.7kg

Operating Temperature:-40°C to +85°C
